| Number of axes | 6 |
| Maximum wrist payload (Kg) | 370 |
| Additional load on forearm (Kg) | 50 |
| Maximum horizontal reach (mm) | 2703 |
| Torque on axis 4 (Nm) | 2109 |
| Torque on axis 5 (Nm) | 2109 |
| Torque on axis 6 (Nm) | 1177 |
| Stroke (Speed) on Axis 1 | +/- 180° (85°/s) |
| Stroke (Speed) on Axis 2 | +75°/ -60° (85°/s) |
| Stroke (Speed) on Axis 3 | -10°/- 231° (85°/s) |
| Stroke (Speed) on Axis 4 | +/- 2700° (90°/s) |
| Stroke (Speed) on Axis 5 | +/- 125° (90°/s) |
| Stroke (Speed) on Axis 6 | +/- 2700° (120°/s) |
| Repeatability (mm) | 0.15 |
| Tool coupling flange | ISO 9409 – 1 – 200 – 6 – M12 |
| Robot weight (Kg) | 2100 |
| Protection class | IP65 / IP67 |
| Mounting position | Floor |
| Operating Areas A (mm) | 3680 |
| Operating Areas B (mm) | 2997 |
| Operating Areas C (mm) | 3195 |
| Operating Areas D (mm) | 433 |
| Operating Areas E (mm) | -118 |
O que o NJ 370-2.7 consegue fazer
Montagem, Fundição, Pressão Flexão-de-freio, Usinagem de Processo, Soldagem a Ponto, Usinagem Madeira / Vidro, Manuseio / Enpacotamento, Corte de Solda a Laser, Tendência para máquina, Medição / Teste, Corte Plasma / Jato de Água, Polimento e Rebarbamento, Usinagem de Processo
NJ 370 – 2.7 Trabalha com
Controladores: CG5
Teach Pendant: TP5
NJ 370 – 2.7 auxiliary systems
Posicionadores: MP – TR – PDTV – PTDO
Eixos externos: External Axes
Slides: TMF
